Image Sensor
1/2.7”, 5.0 megapixel, progressive scan, CMOS
Minimum Illumination
Colour: 0.001 Lux (F1.0, AGC ON); 0 Lux with IR
Features
HLC; BLC; 120dB WDR
Lens Type
Fixed
Focal Length
4mm at F1.2
DORI
Detect: 90m; Observe: 36m; Recognize: 18m; Identify: 9m
Compression
H.265+ / H.265 / H.264 / MJPEG
Storage
Micro SD slot, up to 256 GB
Power Supply
DC 12V±25%, PoE (IEEE 802.3af )
Compliance
NDAA
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1 ~ 1/100 000s
Minimum Illumination
Colour: 0.001 Lux (F1.0, AGC ON); 0 Lux with IR
S/N Ratio
More than 56dB
DORI Distance
Detect: 90m; Observe: 36m; Recognize: 18m; Identify: 9m
IR On/Off Control
Auto/Manual
IR Distance
Distance up to 30m (98ft)
Wide Dynamic Range
120dB
Compliance
NDAA
Backlight Compensation
Supported
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2
Noise Reduction
2D/3D DNR
HLC
Supported
Defog
Digital Defog
Privacy Masking
Up to 4 areas
OSD
Up to 8 OSDs
Smart IR
Supported
ROI
Up to 8 areas
Lens Type
Fixed
Focal Length
4mm
Viewing Angle
H: 80.2°; V: 43.0°; O: 94.7°
Pan/Tilt/Rotate
Pan: 0° ~ 360°; Tilt: 0 ~ 90°; Rotate: 0° ~ 360°
Compression
H.265+ / H.265 / H.264 / MJPEG
H.264 code profile
Baseline profile, Main profile, High profile
Frame Rate
Main Stream: 2880 x 1620, Max 30fps; 2560 x 1440, Max 30fps; 1920 x 1080, Max 30fps; Sub Stream: 1280 x 720, Max 30fps; 720 x 576, Max 30fps; 640 x 360,Max 30fps; 704 x 288, Max 30fps; 352 x 288, Max 30fps; Third Stream: 720 x 576, Max 30fps; 640 x 360,Max 30fps; 704 x 288, Max 30fps; 352 x 288, Max 30fps;
Bit Rate
128 Kbps ~ 16 Mbps
Alarm I/O
1/1
Ethernet
1 x RJ45 10M/100M Base-TX Ethernet
Protocols
IPv4, IPv6 ,IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS, SSH
Compatibility
ONVIF (Profile S, Profile G, Profile T), API, SDK
Web Browser
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above // Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
Management Software
LEGEND VMS, Arkiv
Audio I/O
1 x Input: impedance 35kΩ; amplitude 2V [p-p]; 1x Output: impedance 600Ω; amplitude 2V [p-p]
Audio Compression
G.711
Audio Bitrate
64 Kbps
Suppression
Supported
Sampling Rate
8KHZ
Two-way Audio
Supported
Edge Storage
Micro SD slot, up to 256 GB
Network Storage
ANR, NAS(NFS)
Smart Intrusion Prevention
Support false alarm filtering: Cross Line detection, Intrusion detection, Enter Area detection, Leave Area detection
Statistical Analysis
People counting, support people flow counting and crowd density monitoring
Basic Detection
Motion detection, Tampering alarm, Audio detection
General Function
Watermark, IP address filtering, tampering alarm, access policy, ARP protection, RTSP authentication, user authentication
EMC
FCC CFR 47 Part 15; EN 55032:2015; EN 55024:2010; EN 61000-3-2:2014; EN 61000-3-3-2013
Safety
IEC 62368-1; EN 62368-1; UL 62368-1
Environment
CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Power Supply
DC 12V±25%, PoE (IEEE 802.3af)
Power Consumption
Less than 9W
Working Environment
-30° C to +60° (-22°F ~ 140°F) / Less than 95% RH (non-condensing)
Protection
IK10 & IP67
Weight
2.02lbs (0.92kg)
Dimensions
246× 86 × 85mm (9.7” × 3.4” × 3.3”)
Material
Metal
