Image Sensor
1/2.7”, 5.0 megapixel, progressive scan, CMOS
Minimum Illumination
Colour: 0.002 Lux (F1.6, AGC ON); 0 Lux with IR
Features
HLC; BLC; 120dB WDR
Lens Type
Fixed
Focal Length
2.8mm at F1.6
DORI Distance
Detect: 63m; Observe: 25.2m; Recognize: 12.6m; Identify: 6.3m
Compression
H.265+ / H.265 / H.264 / MJPEG
Storage
Micro SD slot, up to 256 GB
Power Supply
DC 12V±25%, PoE (IEEE 802.3af )
Compliance
NDAA
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1 ~ 1/100 000s
Minimum Illumination
Colour: 0.002 Lux (F1.6, AGC ON); 0 Lux with IR
S/N Ratio
More than 56dB
DORI Distance
Detect: 63m; Observe: 25.2m; Recognize: 12.6m; Identify: 6.3m
Noise Reduction
2D/3D DNR
HLC
Supported
Compliance
NDAA
IR Distance
Distance up to 30M (98ft)
Wavelength
850nm
IR On/Off Control
Auto/Manual
Wide Dynamic Range
120dB
Day/Night
IR-cut filter with auto switch (ICR)
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked
Defog
Digital Defog
Privacy Masking
Up to 4 areas
OSD
Up to 8 OSDs
Smart IR
Supported
Lens Type
Fixed
Focal Length
2.8mm at F1.6
Viewing Angle
H: 112.9°; V: 59.1°; O: 121.2°
Pan/Tilt/Rotate
Pan: 0° ~ 360°; Tilt: 0 ~ 90°; Rotate: 0° ~ 360°
Compression
H.265+ / H.265 / H.264 / MJPEG
H.264 code profile
Baseline profile, Main profile, High profile
Frame Rate
Main Stream: 2880 x 1620, Max 30fps; 2560 x 1440, Max 30fps; 2304 x 1296, Max 30fps; 1920 x 1080, Max 30fps // Sub Stream: 1280 x 720, Max 30fps; 720 x 576, Max 30fps; 640 x 360,Max 30fps; 704 x 288, Max 30fps; 352 x 288, Max 30fps // Third Stream: 720 x 576, Max 30fps; 640 x 360,Max 30fps; 704 x 288, Max 30fps; 352 x 288, Max 30fps
Bit Rate
128 Kbps ~ 16 Mbps
Alarm Light
Supported
Ethernet
1 x RJ45 10M/100M Base-TX Ethernet
Protocols
IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSH
Compatibility
ONVIF (Profile S, Profile G, Profile T), API, SDK
User/Host
Up to 32 users. 2 user levels: administrator and common user
Security
Password protection, strong password, HTTPS encryption, Export operation logs, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
Web Browser
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above; Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
Management Software
LEGEND VMS, Arkiv
Audio Compression
G.711U, G.711A
Audio Bitrate
64 Kbps
Suppression
Supported
Sampling Rate
8KHZ
Two-way Audio
Supported
Built-in Microphone
Yes
Built-in Speaker
Yes
Edge Storage
Micro SD slot, up to 256 GB
Network Storage
ANR, NAS(NFS)
Smart Detection
Support false alarm filtering, Line crossing detection, Intrusion detection, Entering/Leaving Area Detection
Statistical Analysis
People counting, support people flow counting, and crowd density monitoring
Basic Detection
Motion detection, Tampering alarm, Audio detection
General Function
Watermark, IP address filtering, tampering alarm, access policy, ARP protection, RTSP authentication, user authentication
EMC
CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
Safety
CE LVD (EN 62368-1:2014+A11:2017) CB (IEC 62368-1:2014) UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Environment
CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Power Supply
DC 12V±25%, PoE (IEEE 802.3af)
Power Consumption
Less than 11.5W
Working Environment
-30° C to +60° (-22°F ~ 140°F) / Less than 95% RH (non-condensing)
Protection
IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013); 4KV (Surge Protection)
Weight
1.1lbs (0.50kg)
Dimensions
191 x 75 x 74mm (7.5” x 3.0” x 2.9”)
Material
Metal
