Image Sensor
1/3”, 4 megapixel, progressive scan, CMOS
Minimum Illumination
Color: 0.01 Lux (F2.0, AGC On); 0 Lux with IR on
S/N Ratio
More than 56dB
IR Distance
Distance up to 30m (98ft)
Day/Night
IR-cut filter with auto switch (ICR)
Smart IR
Support
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto 2
Video Bit Rate
128 Kbps~6144 Kbps
Noise Reduction
2D/3D DNR
Features
HLC; BLC; DWDR
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1~1/100,000 s
Image Setting
Image rotation, brightness, saturation, contrast, sharpness, gain adjustable by web browser
Flip
Normal/Vertical/Horizontal/180°
Privacy Mask
Up to 4 areas
On-Screen Display (OSD)
Up to 4 OSDs
Region of Interest
Up to 8 areas
Video Stream
Double
Defog
Digital Defog
Lens Type
Fixed
Focal Length
2.8mm
Wavelength
850nm
Viewing Angle
H: 97.0°; V: 52.2°; D: 107.5°
IR On/Off Control
Auto/Manual
Pan/Tilt/Rotate
Pan: 3° ~ 360°; Tilt: 0 ~ 90°; Rotate: 0 ~ 360°
DORI Distance
Detect: 63.0m; Observe: 25.2m; Recognize: 12.6m; Identify: 6.3m
Compression
H.265+, H.265, H.264, MJPEG
H.264 code profile
Baseline profile, Main profile, High profile
Frame Rate
Main Stream: 4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps Sub Stream: D1 (720*576), Max 30fps; 640*360, Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps
Edge Storage
Micro SD, up to 128GB
Network Storage
ANR, NAS(NFS)
Ethernet
1 RJ45 10M/100M Base-TX Ethernet
Protocols
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS, SSL/TLS, SNMP
Compatibility
ONVIF (Profile S, Profile G, Profile T), API, SDK
Security
Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
User/Host
Up to 32 users. 2 user levels: administrator and common user
Management Software
LEGEND VMS / ARKIV
Web Browser
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above; Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
EMC
CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035) FCC (FCC 47 CFR part15 B)
Safety
CE LVD (EN 62368-1) CB (IEC 62368-1) UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1)
Power Supply
DC 12V±25%, PoE (IEEE 802.3af)
Power Consumption
Less than 5.5W
Working Environment
-30°C to 60°C (-22°F to 140°F) / Less than 95% RH
Material
Metal + Graphene
Protection
IP67 (IEC 60529) 4KV (Surge Protection)
Weight
0.86 lb (0.39kg)
Dimensions
165 × 63 × 62mm (6.5” × 2.5” × 2.5”)
Basic Detection
Cross line, intrusion(based on human body detection), motion detection, Ultra motion detection, tampering alarm, audio detection
General Functions
Watermark, IP address filtering, alarm input, alarm output, access Policy, ARP protection, RTSP authentication, user authentication
Environment
CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU);
Power Interface
Ø 5.5mm coaxial power plug
