Inputs/Outputs
With Inputs/Outputs
Audio In/Out
With Audio Inputs and/or Outputs
NDAA Compliant
Yes
Wide Dynamic Range
WDR less than 120dB
Form Factor
Hemispheric Cameras
Megapixels
12 Megapixels
Lens Type
Hemispheric Cameras
Image Sensor
1/1.7”, 12.0 megapixel, progressive scan, CMOS
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1 ~ 1/100 000s
Minimum Illumination
Colour: 0.03Lux (F2.0, AGC ON) / 0 Lux with IR on
S/N Ratio
More than 52dB
IR Distance
Distance up to 15m (49ft)
Wavelength
850nm
BLC & Smart IR
Supported
IR On/Off Control
Auto/Manual
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2
BLC & Smart IR
Supported
Wide Dynamic Range
DWDR
Digital Noise Reduction
2D/3D DNR
Flip
Normal / Vertical / Horizontal / 180°
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2
Defog
Digital Defog
Privacy Masking
Up to 4 areas
Digital Noise Reduction
2D/3D DNR
OSD
Up to 8 OSDs
Privacy Masking
Up to 4 areas
Dewarping
Supports both hardware and software dewarp
Flip
Normal / Vertical / Horizontal / 180°
OSD
Up to 8 OSDs
ROI
Up to 8 areas
Defog
Digital Defog
Dewarping
Supports both hardware and software dewarp
Frame Rate
Main Stream: Fisheye: 4000x3000 at 20fps; 3000x3000 at 20fps; 2560x2560 at 25fps / Pan: 4000x3000 at 20fps; 3000x2000 at 20/25fps; 3000x1500 at 20/25fp / PTZ: 1920x1080 at 20/25fps
Focal Length
2.8mm
ROI
Up to 8 areas
Field of View
360°
Focal Length
2.8mm
Alarm I/O
2/1
DORI Distance - Lens 2.8mm
Detect: 43.8m; Observe: 17.5m; Recognize: 8.8m; Identify: 4.4m
Field of View
360°
Day / Night
IR-cut filter with auto switch (ICR)
DORI Distance - Lens 2.8mm
Detect: 43.8m; Observe: 17.5m; Recognize: 8.8m; Identify: 4.4m
Compression
H.265+ / H.265 / H.264 / MJPEG
Audio I/O
Input: impedance 35k; amplitude 2V [p-p] / Output: impedance 600; amplitude 2V [p-p]
Lens Type
Fixed
Bit Rate
128 Kbps ~16 Mbps
Audio I/O
Input: impedance 35k; amplitude 2V [p-p] / Output: impedance 600; amplitude 2V [p-p]
Compression
H.265+ / H.265 / H.264 / MJPEG
Built-in Microphones
Two Mics
Frame Rate
Main Stream: Fisheye: 4000x3000 at 20fps; 3000x3000 at 20fps; 2560x2560 at 25fps / Pan: 4000x3000 at 20fps; 3000x2000 at 20/25fps; 3000x1500 at 20/25fp / PTZ: 1920x1080 at 20/25fps // Sub Stream Fisheye: 2000x1500 at 20fps; 2000x2000 at 25fps // Third Stream Fisheye: 720x576 at 20/25fps; 352x288 at 20/25fps
Edge Storage
Micro SD slot, up to 256 GB
Bit Rate
128 Kbps ~16 Mbps
Smart intrusion prevention
Cross Line detection, Intrusion detection
Alarm I/O
2/1 (Multiple Alarm linkage editable)
Statistical Analysis
Heat map (Working with Management Platform)
Detection
Motion detection, Ultra motion detection, Tampering alarm, Audio detection
Ethernet
1 x RJ45 10M/100M Base-TX Auto-adaptive Ethernet
Power Supply
DC 12V±25%, PoE (IEEE 802.3af )
Protocol
IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS
Power Consumption
Less than 12W
Built-in Microphones
Two Mics
User/Host
Up to 32 users. 3 user levels: administrator, common user and operator
Working Environment
-30° C to +60° (-22°F ~ 140°F) / Less than 95% RH (non-condensing)
Security
Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
Ingress & Vandal Protection
IP67 & IK10
Compatibility
ONVIF (Profile S, Profile G, Profile T), API, SDK
Weight
524g
Management Software
LEGEND VMS, Arkiv
Dimensions
149 x 55mm (5.9” x 2.2”)
Web Browser
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above
Built-in Speaker
Supported
Serial
1 Channel RS485 Interface
Audio Compression
G.711U, G.711A
Two-way Audio
Supported
Suppression
Supported
Audio Bitrate
64 Kbps
Sampling Rate
8KHZ
Edge Storage
Micro SD slot, up to 256 GB
Network Storage
ANR, NAS(NFS)
Smart intrusion prevention
Cross Line detection, Intrusion detection
Statistical Analysis
Heat map (Working with Management Platform)
Detection
Motion detection, Ultra motion detection, Tampering alarm, Audio detection
General Function
Watermark, IP Address Filtering, Tampering Alarm ,Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication
Certifications
CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014) CE LVD (EN 62368-1:2014+A11:2017) CB (IEC 62368-1:2014) UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01) CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Power Supply
DC 12V±25%, PoE (IEEE 802.3af )
Power Consumption
Less than 12W
Working Environment
-30° C to +60° (-22°F ~ 140°F) / Less than 95% RH (non-condensing)
Ingress & Vandal Protection
IP67 & IK10
Weight
524g
Dimensions
149 x 55mm (5.9” x 2.2”)
