Image Sensor
1/3”, 4.0 megapixel, progressive scan, CMOS
Minimum Illumination
Color: 0.003 Lux (F1.6, AGC ON) / 0Lux with IR on
Pan/Tilt/Rotate
Pan: 0° ~ 360°; Tilt: 0 ~ 80°; Rotate: 0° ~ 360°
DORI Distance
Detect: 63m; Observe: 25.2m; Recognize: 12.6m; Identify: 6.3m
Compression
H.265+ / H.265 / H.264 / MJPEG
Frame Rate
Main Stream: 4MP (2688*1520), Max 25fps; 4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps. Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps;
Region of Interest
Up to 8 areas
Video Stream
Double
Flip
Normal / Flip Vertical / Flip Horizontal / 180°/ 90°Clockwise / 90°Anti-clockwise
Basic Detection
Cross line, intrusion(based on human body detection), motion detection, Ultra motion detection, tampering alarm, audio detection
Wavelength
850nm
Focal Length
2.8mm
User/Host
Up to 32 users. 3 user levels: administrator, common user and operator
Web Browser
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above; Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
EMC
CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
Safety
CE LVD (EN 62368-1:2014+A11:2017) CB (IEC 62368-1:2014) UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Protocols
IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL/TLS, 802.1x, SNMP
Compatibility
ONVIF (Profile S, Profile G, Profile T), API, SDK
Security
Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF, Password protection, Strong password, HTTPS encryption
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1 ~ 1/100 000s
S/N Ratio
More than 56dB
IR Distance
Distance up to 30M (98ft)
IR On/Off Control
Auto/Manual
Wide Dynamic Range
120dB
Day/Night
IR-cut filter with auto switch (ICR)
General Functions
Watermark, IP address filtering, alarm input, alarm output, access Policy, ARP protection, RTSP authentication, user authentication
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto 2
Noise Reduction
2D/3D DNR
Features
HLC; BLC; Corridor Mode
Defog
Digital Defog
Privacy Mask
Up to 4 areas
On-Screen Display (OSD)
Up to 8 OSDs
Smart IR
Supported
Audio Bit Rate
64 Kbps
Lens Type
Fixed
Viewing Angle
H: 101.1°; V: 55.3°; D: 111.1°
Ethernet
1 RJ45 10M/100M Base-TX Ethernet
H.264 code profile
Baseline profile, Main Profile, High Profile
Video Bit Rate
128 Kbps ~ 16 Mbps
Management Software
LEGEND VMS / ARKIV
Audio Compression
G.711
Suppression
Supported
Sampling Rate
8KHZ
Built-in Mic
Yes
Edge Storage
Micro SD slot, up to 256 GB
Network Storage
ANR, NAS(NFS)
Environnemnt
CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection
IP67 (IEC 60529:1989 + AMD1:1999+AMD2:2013) 2KV (Surge Protection)
Detection
Motion detection, tampering alarm, audio detection
General Functions
Watermark, IP address filtering, alarm input, alarm output, access Policy, ARP protection, RTSP authentication, user authentication
Certifications
CE LVD (EN 62368-1:2014+A11:2017); UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01); FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
Power Supply
DC 12V ± 25%, PoE (IEEE 802.3af)
Power Consumption
Less than 6.0W
Working Environment
-30° C ~ +60° C / Less than 95% RH
Power Interface
Ø 5.5mm coaxial power plug
Surge Protection
4KV
Material
Metal
Weight
0.77lb / 0.35kg
Dimensions
Ø 118 x 95mm (Ø4.6’’ x 3.8’’)
