Image Sensor
1/2.8”, 4 megapixel, progressive scan, CMOS
Minimum Illumination
Color: 0.003 Lux (F1.5, AGC ON); 0 Lux with IR
Focal Length
4.8 ~ 120mm,, Motorized zoom lens
DORI Distance
Wide (4.8mm): Detect 119.3m; Observe 47.7m; Recognize 23.9m; Identify 11.9m / Telemetry (120mm): Detect 2475m; Observe 990m; Recognize 495m; Identify 247.5m
Compression
H.265+ / H.265 / H.264+ / H.264 / MJPEG
Frame Rate
Main Stream: 4MP(2688x1520),Max 30fps; Sub Stream: 2MP (1920x1080), Max 30fps; Third Stream: D1 (720x576), Max 30fps; Fourth Stream: D1 (720x576), Max 30fps; Fifth Stream: D1 (720x576), Max 30fps
Edge Storage
Micro SD slot, up to 256 GB
Power Supply
DC12V(±25%,3A), PoE+(IEEE 802.3at)
Weight
6.72 lbs (3.05kg)
Dimensions
Ø166 x 295mm (Ø6.5” x 11.6”)
Compliance
NDAA
Minimum Illumination
Color: 0.003 Lux (F1.5, AGC ON); 0 Lux with IR
Focal Length
4.8 ~ 120mm,, Motorized zoom lens
DORI Distance
Wide (4.8mm): Detect 119.3m; Observe 47.7m; Recognize 23.9m; Identify 11.9m / Telemetry (120mm): Detect 2475m; Observe 990m; Recognize 495m; Identify 247.5m
Compression
H.265+ / H.265 / H.264+ / H.264 / MJPEG
Frame Rate
Main Stream: 4MP(2688x1520),Max 30fps; Sub Stream: 2MP (1920x1080), Max 30fps; Third Stream: D1 (720x576), Max 30fps; Fourth Stream: D1 (720x576), Max 30fps; Fifth Stream: D1 (720x576), Max 30fps
Storage
ANR; NAS; Micro SD card up to 256GB
Power Supply
DC12V(±25%,3A), PoE+(IEEE 802.3at)
Weight
6.72 lbs (3.05kg)
Dimensions
Ø166 x 295mm (Ø6.5” x 11.6”)
Compliance
NDAA
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1 ~ 1/100,000s
S/N Ratio
More than 56 dB
IR Distance
Up to 100m (328 ft) IR range
IR On/Off Control
Auto/Manual
Day/Night
IR-cut filter with auto switch (ICR)
Features
BLC / HLC / WDR(120dB)
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2
OSD
Up to 8 OSDs
Noise Reduction
2D/3D DNR
Digital Zoom
16x
Privacy Masking
Up to 24 areas
Region of Interest
Supported
U-Code
Supported
Defog
Digital Defog
Flip
Normal / Vertical / Horizontal / 180° / 90° Clockwise / 90° Counter-Clockwise
Max. Aperture
F1.5 – F3.8
Viewing Angle
H: 52.20°~2.74°; V: 30.81°~1.54°; O: 64.20°~3.23°
Optical Zoom
25x
Video Bit Rate
128 Kbps ~ 16 Mbps
Audio Compression
G.711A / G.711U
Two-way Audio
Supported
Suppression
Supported
Sampling Rate
8KHZ
Audio Bitrate
64 Kbps
Smart Intrusion Prevention
Support false alarm filtering: Cross Line detection, Intrusion detection, Region entrance detection, Region exit detection
Basic Detection
Motion detection, Ultra motion detection, Tampering alarm, Audio detection
General Functions
Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication
Number of Presets
1024
Pan Range
360° (endless)
Pan Speed
0.1°/s ~ 200°/s; Preset speed: 240°/s
Tilt Range
–15° ~ 90° (auto reverse)
Tilt Speed
0.1°/s ~ 120°/s; Preset speed: 200°/s
Preset Patrol
16 patrols, up to 64 presets for each patrol
Route Patrol
16 patrols, up to 32 actions for each patrol
Recorded Patrol
16 patrols, up to 128 actions for each patrol
Patrol Stay Time
15s~1800s
Preset Image Freeze
Supported
Home Position
Supported
Ethernet
RJ45 10M/100M Base-TX Ethernet
Protocols
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP
Compatibility
ONVIF (Profile S, Profile G, Profile T), API,SDK
Security
Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
Video Software Management
Legend VMS, Arkiv
Smart Phone
iOS, Android
Video out
1 BNC
RS485
1
Audio In/Out
1/1
Alarm In/Out
2/1
Power Supply
DC12V(±25%,3A), PoE+(IEEE 802.3at)
Power Interface
Ø 5.5mm coaxial power plug
Power Consumption
Less than 21W
Working Environment
-40°C to 70°C (-40°F ~ +158°F); Less than 95% RH
Protection
IP67; IK10
Auto Tracking
Yes
Statistical Analysis
People counting, support people flow counting and crowd density monitoring
Reset Button
Supported
