Image Sensor
1/2.8” 2MP CMOS
Minimum Illumination
0.001 Lux (F1.6)
Electronic Shutter Speed
Auto/Manual, Range: 1/25 to 1/100,000
Lens (Focal Length)
4.7 to 47mm, motorized zoom
Pixel Size
17um
Image collection format
1080P@25 (default), 1080P@30, 1080P@50, 1080P@60
Pixel Size
17um
Response Waveband
8um to 14um
Response Waveband
8um to 14um
Resolution
Main stream: 1080P (default), 720P, D1 Sub stream: 720P (default), D1, 2CIF, CIF Third stream: D1 (default), 2CIF, CIF
Field of View
65.9° × 45.9° (H × V)
Frame Rate
60, 50, 30, 25 (default), 22, 20, 18, 16, 15, 12.5,10, 8, 6, 5, 4, 3, 2, 1
Compression
H.265; H.264
Image Settings
Thermal Shutter, Contrast Enhancement, Palette, Text Overlay
ROI
Supports up to 8 regions
Image Settings
Thermal Shutter, Contrast Enhancement, Palette, Text Overlay
Frame Rate
1080P at 25fps (Default), 30fps, 50fps, 60fps
Video OSD
Supports 8 overlay areas and allows contents including date, time, date & time, zoom ratio, custom contents
Resolution
Main stream: 1080P (default), 720P, D1 Sub stream: 720P (default), D1, 2CIF, CIF Third stream: D1 (default), 2CIF, CIF
Image OSD
Supports 8 overlay areas and allows contents including time, license plate number, device ID, camera ID, allowlist, image authentication ID, custom contents (3 items), location
Image Sensor
Uncooled LWIR Image Sensor
Compression
H.265; H.264
Application scenario
Vehicle speed ≤30km/h Supports simultaneous application to entry/exit scenes
Video OSD
Supports 8 overlay areas and allows contents including date, time, date & time, zoom ratio, custom contents
Vehicle detection mode
Video (default) or inductive loop
Capture vehicule head only
Support
Image OSD
Supports 8 overlay areas and allows contents including time, license plate number, device ID, camera ID, allowlist, image authentication ID, custom contents (3 items), location
Capture vehicle head only
Support
License plate number recognition
Supports recognition of license plates with numbers and letters by default
Power Supply
DC12V+ 25% - 10% / Max. power consumption: 20W
List configuration
Supports allowlist and blocklist configuration, each list allows 20,000 items; Supports import, export, add, and delete operations
Barrier opening policy
Open barrier only for the recognized vehicles; Open barrier for all vehicles; Open barrier only for vehicles on the allowlist; Open barrier for vehicles not on the blocklist; Configurable Boolean output ID
Edge storage
Supports ANR with a Micro SD card, up to 128GB
Edge storage
Supports ANR with a Micro SD card, up to 128GB
Illumination
Built-in integrated illumination module, including 4 IR LEDs, 50m illumination distance, automatic on/off control
Sunshield
Long sunshield
Bracket
3-axis mounting bracket
Junction box
The camera comes with a junction box for storing tail cable
Network interface
1 × 10M/100M RJ45
Serial port
1 × RS485
Boolean output
1 relay output, withstand voltage: AC 125V/0.3A, DC 30V/1A
Boolean input
2 inputs, supports level/Boolean, with max level up to DC 5V
Audio interface
1 × audio input, 1 × audio output
Storage interface
1 × Micro SD card slot
Power Supply
DC12V+ 25% - 10% / Max. power consumption: 20W
PoE
Supports PoE (802.3at, class 4)
Protection
IP67, IK10
Dimensions
386mm x 126mm x 130mm
Operating environment
-40℃ to 60℃, ≤90% RH
Weight
2kg
