Image Sensor
1/3’’ 4 Megapixels progressive scan CMOS
Minimum Illumination
Color: 0.003 Lux (F1.6, AGC On); 0 Lux with IR on
Wavelength
850nm
IR On/Off Control
Auto/Manual
Day/Night
IR-cut filter with auto switch (ICR)
Wide Dynamic Range
120dB
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2
Noise Reduction
2D/3D DNR
Features
HLC; BLC
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1~1/100,000 s
S/N Ratio
Less than 56dB
IR Distance
Distance up to 50m (164ft)
Privacy Masking
Up to 4 areas
OSD
Up to 4 OSDs
Region of Interest
Up to 8 areas
Lens Type
Motorized Lens
Focal Length
2.8mm ~ 12mm
Viewing Angle
H: 102.79° ~ 30.86°; V: 54.50° ~ 17.49°; O: 106.94° ~ 35.49°
Pan/Tilt/Rotate
Pan: 0° ~ 360°; Tilt: 0 ~ 90°; Rotate: 0 ~ 360°
DORI Distance
Detect(2.8mm): 63.0m; Detect(12mm): 270m; Observe(2.8mm): 25.2m; Observe(12mm): 108m; Recognize(2.8mm): 12.6m; Recognize(12mm): 54m; Identify(2.8mm): 6.3m; Identify(12mm): 27m
Compression
H.265+, H.265, H.264, MJPEG
H.264 code profile
Baseline profile, Main profile, High profile
Frame Rate
Main Stream: 4MP (2688x1520), Max 25fps; 4MP (2560x1440), Max 25fps; 3MP (2304x1296), Max 30fps; 1080P (1920x1080), Max 30fps // Sub Stream: 720P (1280x720), Max 30fps; D1 (720x576), Max 30fps; (640x360), Max 30fps
Basic Detection
Cross line, Intrusion (based on human body detection); Motion detection, Ultra motion detection, Tampering alarm, Audio detection
General Function
Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP Authentication
Ethernet
1 x RJ45 10M/100M Base-TX Ethernet
Protocols
IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL/TLS, QoS, 802.1x, SNMP, PPPoE
Compatibility
ONVIF (Profile S, Profile G, Profile T), API, SDK
Security
Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
Management Software
LEGEND VMS, Arkiv
Web Browser
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above // Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
Edge Storage
Micro SD card, up to 256GB
Network Storage
ANR, NAS (NFS)
Built-in Mic
Supported
Audio Compression
G.711U, G.711A
Audio Bitrate
64 Kbps
Suppression
Supported
Sampling Rate
8KHZ
EMC
CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035) FCC (FCC 47 CFR part15 B)
Safety
CE LVD (EN 62368-1) CB (IEC 62368-1) UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1)
Power Supply
DC 12V±25%, PoE (IEEE 802.3af)
Power Consumption
Less than 8.5W
Working Environment
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Protection
IP67 (IEC 60529-2013) 6KV (Surge Protection)
Weight
1.2 lbs (0.55kg)
Dimensions
206 × 74 × 74mm (8.1” × 2.9” × 2.9”)
Video Bit Rate
128 Kbps~16 Mbps
Video Stream
Double
Smart IR
Supported
Flip
Normal / Flip Vertical / Flip Horizontal / 180°/ 90°Clockwise / 90°Anti-clockwise
Defog
Digital Defog
User/Host
Up to 32 users. 3 user levels: administrator, common user and operator
Environnemnt
CE-ROHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU);
Power Interface
Ø 5.5mm coaxial power plug
Material
Metal
Reset Button
Supported
