Inputs/Outputs
With Inputs/Outputs
Form Factor
Dome
Audio In/Out
With Audio Inputs and/or Outputs
NDAA Compliant
Yes
Wide Dynamic Range
WDR 120dB or more
Lens Type
Fixed
Megapixels
4 Megapixels
Image Sensor
2 x 1/3.0”, 4.0 megapixel, progressive scan, CMOS
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1 ~ 1/100 000s
Minimum Illumination
Colour: 0.002 (F1.6, AGC ON) 0 lux with IR
S/N Ratio
More than 52dB
IR Distance
Distance up to 30m (98ft)
Wavelength
850nm
Wide Dynamic Range
130dB
Wide Dynamic Range
130dB
IR On/Off Control
Auto/Manual
Backlight Compensation
Supported
Backlight Compensation
Supported
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2
Digital Noise Reduction
2D/3D DNR
Digital Noise Reduction
2D/3D DNR
Flip
Normal / Vertical / Horizontal / 180° / 90° Clockwise / 90° Anti-clockwise
Flip
Normal / Vertical / Horizontal / 180° / 90° Clockwise / 90° Anti-clockwise
Defog
Digital Defog
Defog
Digital Defog
Privacy Masking
Up to 4 areas
Privacy Masking
Up to 4 areas
OSD
Up to 8 OSDs
OSD
Up to 8 OSDs
HLC
Supported
HLC
Supported
Smart IR
Supported
Smart IR
Supported
ROI
Up to 8 areas
Focal Length
2.8mm
Day/Night
IR-cut filter with auto switch (ICR)
Adjustment Angle
Pan: 0° ~ 180°; Tilt: 0° ~ 66°; Rotate: 0° ~ 346°
Focal Length
2.8mm
Frame Rate
Main Stream: 4MP(2688x1520) Max 25fps; 4MP(2560x1440) Max 25fps; 3MP(2304x1296) Max 30fps; 1080P (1920x1080), Max 30fps; 720P(1280x720) Max 30fps
ROI
Up to 8 areas
DORI Distance - 2.8mm Lens
Detect: 63.0m(206.7ft); Observe: 25.2m(82.7ft); Recognize: 12.6m(41.3ft); Identify: 6.3m(20.7ft)
DORI Distance - 2.8mm Lens
Detect: 63.0m(206.7ft); Observe: 25.2m(82.7ft); Recognize: 12.6m(41.3ft); Identify: 6.3m(20.7ft)
Lens Type
Fixed
Compression
H.265+ / H.265 / H.264 / MJPEG
Adjustment Angle
Pan: 0° ~ 180°; Tilt: 0° ~ 66°; Rotate: 0° ~ 346°
Bit Rate
128 Kbps ~16 Mbps
Bit Rate
128 Kbps ~16 Mbps
Alarm I/O
1/1
Alarm I/O
1/1
Compression
H.265+ / H.265 / H.264 / MJPEG
Ethernet
1 RJ45 10M/100M Base-TX Ethernet
User/Host
Up to 32 users. 3 user levels: administrator, common user and operator
H.264 code profile
Baseline profile, Main profile, High profile
Protocol
IPv4,IPv6, IGMP, ICMP ,ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, SSL/ TLS, SSH
Frame Rate
Main Stream: 4MP(2688x1520) Max 25fps; 4MP(2560x1440) Max 25fps; 3MP(2304x1296) Max 30fps; 1080P (1920x1080), Max 30fps; 720P(1280x720) Max 30fps // Sub Stream: 720P (1280x720), Max 30fps; D1 (720x576), Max 30fps; 640x360,Max 30fps; 2CIF(704x288), Max 30fps; CIF(352x288), Max 30fps // Third Stream: D1 (720x576), Max 30fps; 640x360, Max 30fps; 2CIF (704x288), Max 30fps; CIF (352x288), Max 30fps
User/Host
Up to 32 users. 3 user levels: administrator, common user and operator
Security
Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2 , WSSE and digest authentication for ONVIF
Audio I/O
Input: impedance 35k; amplitude 2V [p-p] Output: impedance 600; amplitude 2V [p-p]
Audio I/O
Input: impedance 35k; amplitude 2V [p-p] Output: impedance 600; amplitude 2V [p-p]
Ethernet
1 RJ45 10M/100M Base-TX Ethernet
Audio Compression
G.711U, G.711A
Protocol
IPv4,IPv6, IGMP, ICMP ,ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, SSL/ TLS, SSH
Two-way Audio
Supported
Built-in Microphones
Two Mics
Security
Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2 , WSSE and digest authentication for ONVIF
Edge Storage
Micro SD slot, up to 256 GB
Compatibility
ONVIF (Profile S, Profile T, Profile G), API,SDK
Recognition
Face Capture (Only Channel 1)
Management Software
LEGEND VMS, Arkiv
Detection
Motion detection, Ultra motion detection, Tampering alarm, Audio detection
Web Browser
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above // Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
Power Supply
DC 12V±25%, PoE (IEEE 802.3af )
Power Consumption
Less than 9.1W
Audio Compression
G.711U, G.711A
Working Environment
-30° C to +60° (-22°F ~ 140°F) / Less than 95% RH (non-condensing)
Two-way Audio
Supported
Ingress & Vandal Protection
IP67 & IK10
Suppression
Supported
Weight
0.62kg(1.37lb)
Audio Bitrate
64 Kbps
Dimensions
176×104×72mm (6.9” × 4.1’’ ×2.8”)
Sampling Rate
8KHZ
Built-in Microphones
Two Mics
Edge Storage
Micro SD slot, up to 256 GB
Network Storage
ANR, NAS(NFS)
Smart intrusion prevention
Support false alarm filtering: Line crossing detection, Intrusion detection, Enter Area detection, Leave Area detection
Recognition
Face Capture (Only Channel 1)
Statistical Analysis
People counting, support people flow counting and crowd density monitoring(Only Channel 1)
Detection
Motion detection, Ultra motion detection, Tampering alarm, Audio detection
General Function
Watermark, IP address filtering, Tampering alarm, Access policy, ARP protection, RTSP authentication, User authentication
Certifications
EMC: CE-EMC (EN 55032, EN 61000-3-3,EN IEC 61000-3-2,EN 55035) FCC (FCC 47 CFR part15 B); Safety: CE-LVD (EN 62368-1) UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1); Environment: CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Protection: IP67 (IEC 60529) IK10 (IEC 62262)
Power Supply
DC 12V±25%, PoE (IEEE 802.3af )
Power Consumption
Less than 9.1W
Working Environment
-30° C to +60° (-22°F ~ 140°F) / Less than 95% RH (non-condensing)
Ingress & Vandal Protection
IP67 & IK10
Weight
0.62kg(1.37lb)
Dimensions
176×104×72mm (6.9” × 4.1’’ ×2.8”)
