Image Sensor
1/2.7’’, 5.0 megapixel, progressive scan, CMOS
LED Distance
Distance up to 30M (98ft)
Lens Type
Fixed
Focal Length
2.8mm
DORI Distance
Detect: 63m; Observe: 25.2m; Recognize: 12.6m; Identify: 6.3m
Compression
H.265+ / H.265 / H.264 / MJPEG
Frame Rate
Main Stream: 5MP (2880x1620), Max 25fps; 4MP (2560x1440), Max 25fps; 3MP (2304x1296), Max 25fps; 2MP (1920x1080), Max 30fps
Video Stream
Triple
Ethernet
1 RJ45 10M/100M Base-TX Ethernet
Protocols
IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/ TLS, SSH
Compatibility
ONVIF (Profile S, Profile G, Profile T), API,SDK
Management Software
LEGEND VMS, Arkiv
Image Settings
Image rotation, brightness, saturation, contrast, sharpness, gain adjustable by web browser
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1 ~ 1/100000s
Minimum Illumination
Color: 0.001 Lux (F1.0, AGC ON)
S/N Ratio
More than 56dB
LEDs Number
2
Wide Dynamic Range
120dB
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto 2
Noise Reduction
2D/3D DNR
Features
HLC; BLC
Privacy Mask
Up to 4 areas
On-Screen Display (OSD)
Up to 8 OSDs
Region of Interests
Up to 8 areas
Viewing Angle
H: 102.0°; V: 53.4°; D: 121.0°
Video Bit Rate
128 Kbps~16 Mbps
Pan/Tilt/Rotate
Pan: 3° ~ 360°; Tilt: 0 ~ 80°; Rotate: 3° ~ 360°
H.264 code profile
Baseline profile, Main profile, High profile
Frame Rate
Main Stream: 5MP (2880*1620), Max 30fps; 4MP (2560*1440), Max 30fps; 3MP (2304*1296), Max 30fps; 2MP (1920*1080), Max 30fps; 720P(1280*720), Max 30fps Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360, Max 30fps; Third Stream: D1 (720*576), Max 30fps; 640*360, Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
LED On/Off Control
Auto/Manual
Audio Compression
G.711
Audio Bitrate
64 Kbps
Suppression
Supported
Sampling Rate
8KHZ
Built-in Mic
Supported
Edge Storage
Micro SD slot, up to 256 GB
Network Storage
ANR, NAS(NFS)
Smart Intrusion Prevention
Support false alarm filtering: Cross Line detection, Intrusion detection, Enter Area detection, Leave Area detection
Statistical Analysis
Support tripwire people counting and area people counting
Web Browser
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above; Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
General Function
Watermark, IP address filtering, alarm input, alarm output, access policy, ARP protection, RTSP authentication, user authentication
Basic Detection
Motion detection, tampering alarm, audio detection
Power Supply
DC 12V ± 25%, PoE (IEEE 802.3af)
Power Consumption
Less than 7.5W
Working Environment
-30° C to +60° (-22°F ~ 140°F) / Less than 95% RH (non-condensing)
EMC
FCC CFR 47 Part 15, EN 55032:2015, EN 55024:2010, EN 61000-3-2:2014, EN 61000-3-3-2013
Safety
IEC 62368-1, EN 62368-1, UL 62368-1
Material
Metal
Weight
0.44kg (0.97lb)
Dimensions
Φ110.5 x 94.1mm (Φ4.4” x 3.7”)
Smart Illumination
Supported
Flip
Normal / Flip Vertical / Flip Horizontal / 180°/ 90°Clockwise / 90°Anti-clockwise
Defog
Digital Defog
Environment
CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection
IP67 (IEC 60529-2013), 4KV (Surge Protection)
Power Interface
Ø 5.5mm coaxial power plug
