Image Sensor
1/2.7’’, 5.0 megapixel, progressive scan, CMOS
IR Distance
Distance up to 30M (98ft)
Lens Type
ChromaView Fixed Lens
Focal Length
2.8mm
DORI Distance
Detect: 63m; Observe: 25.2m; Recognize: 12.6m; Identify: 6.3m
Compression
H.265+ / H.265 / H.264 / MJPEG
Frame Rate
Main Stream: 5MP (2880x1620), Max 25fps; 4MP (2560x1440), Max 25fps; 3MP (2304x1296), Max 25fps; 2MP (1920x1080), Max 30fps
Video Stream
Triple streams
Ethernet
1 RJ45 10M/100M Base-TX Ethernet
Protocol
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS
Compatibility
ONVIF (Profile S, Profile G, Profile T), API, SDK
Management Software
LEGEND VMS, Arkiv
Dimensions
110.5 x 94.1mm (4.4” x 3.7”)
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1 ~ 1/100000s
Minimum Illumination
Color: 0.001 Lux (F1.0, AGC ON)
S/N Ratio
More than 56dB
LEDs Number
2
Wide Dynamic Range
120dB
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked
Noise Reduction
2D/3D DNR
Features
HLC; BLC
Privacy Masking
Up to 4 areas
OSD
Up to 8 OSDs
Region of Interests
Up to 8 areas
Viewing Angle
H: 102.0°; V: 53.4°; O: 121.0°
Iris Type
N/A
Pan/Tilt/Rotate
Pan: 3° ~ 360°; Tilt: 0 ~ 80°; Rotate: 3° ~ 360°
H.264 code profile
Baseline profile, Main profile, High profile
Frame Rate
Main Stream: 5MP (2880x1620), Max 25fps; 4MP (2560x1440), Max 25fps; 3MP (2304x1296), Max 25fps; 2MP (1920x1080), Max 30fps // Sub Stream: 720P (1280x720), Max 30fps; D1 (720x576), Max 30fps 640x360, Max 30fps; 2CIF (704x288), Max 30fps; CIF (352*288), Max 30fps // Third Stream: D1 (720x576), Max 30fps; 640x360, Max 30fps; 2CIF (704x288), Max 30fps; CIF (352x288), Max 30fps
U-code
Support
Audio Compression
G.711
Audio Bitrate
64 Kbps
Suppression
Supported
Sampling Rate
8KHZ
Built-in Mic
Supported
Edge Storage
Micro SD slot, up to 256 GB
Network Storage
ANR, NAS(NFS)
Intrusion
Support false alarm filtering: Cross Line detection, Intrusion detection, Enter Area detection, Leave Area detection
Statistical Analysis
Support tripwire people counting and area people counting
Detection
Motion Detection, Tampering Alarm, Audio Detection
General Function
Watermark, IP address filtering, alarm input, alarm output, access policy, ARP protection, RTSP authentication, user authentication
Certifications
IEC 62368-1; EN 62368-1; UL 62368-1; FCC CFR 47 Part 15; EN 55032:2015; EN 55024:2010; EN 61000-3-2:2014; EN 61000-3-3-2013
Power Supply
DC 12V ± 25%, PoE (IEEE 802.3af)
Power Consumption
Less than 4W
Working Environment
-30° C to +60° (-22°F ~ 140°F) / Less than 95% RH (non-condensing)
Ingress Protection
IP67
Surge protection
4KV
Material
Metal
Weight
0.44kg (0.97lb)
Dimensions
Φ110.5 x 94.1mm (Φ4.4” x 3.7”)
