Image Sensor
1/2.7” Progressive Scan CMOS Sensor
Minimum Illumination
Color: 0.006 Lux (F1.6 , AGC ON), 0 Lux with light
Illumination Distance
30m / 98.43ft (IR light) 30m / 98.43ft (Warm light)
Strobe Light
N/A
Smart IR
Supported
Embedded Features
Built-in Mic, Built-in Reset Button, Red & Blue Light Warning, Smart IR Light, Illuminator (Warm Light)
External Features
DC12V ± 25%
Viewing Angle
Pano: 0° ~ 360° ; Tilt: 0° ~ 90° ; Rotation: 0° ~ 360°
Focal Length
2.8mm
Aperture
F1.6
Field of View
2.8mm: Horizontal FoV: 110°, Vertical FoV: 58°, Diagonal FoV: 128°
Thread Mount
M12
Maximum Resolution
8MP (3840 × 2160)
Frame Rate (Main Stream)
50Hz: 20fps 8MP (3840 × 2160), 20fps 6MP (3200 × 1800), 25fps 5MP (3072 × 1728), 25fps 4MP (2560 × 1440), 25fps 1080P (1920 × 1080); 60Hz: 20fps 8MP (3840 × 2160), 20fps 6MP (3200 × 1800), 30fps 5MP (3072 × 1728), 30fps 4MP (2560 × 1440), 30fps 1080P (1920 × 1080)
Frame Rate (Sub Stream)
50Hz: 25fps 720P (1280 × 720), 25fps D1 (704 × 576), 25fps CIF (352 × 288) (Default D1); 60Hz: 30fps 720P (1280 × 720), 30fps D1 (704 × 480), 30fps CIF (352 × 240)
Frame Rate (Third Stream)
50Hz: 25fps CIF (352 × 288); 60Hz: 30fps CIF (352 × 240)
Image Calibration
Brightness / Contrast / Saturation / Hue / Sharpness
Shutter Time
Auto/Manual, 1/3 ~ 1/100000s
Day/Night
IR Cut Filter
Wide Dynamic Range
True 120 dB
Digital Noise Reduction
DNR 2D/3D
Image Features
Backlight Compensation (BLC), Highlight Compensation (HLC), Region of Interest (ROI), Rotation
HLC
Supported
ROI
Supported
Video Compression
H.265+ / H.265/H.264 / H.264+ / MJPEG (Sub Stream)
Rotate
Supported
H.265 Codec Profile
Main Profile
H.264 Codec Profile
Base / Main / High profile
Video Bit Rate
11 Kbps ~ 13 Mbps
Video Stream
Triple
Audio Compression
G.711A, G.711U
Audio Bit Rate
64 Kbps
Basic Events
Motion detection, Video tampering
Smart Events
Advanced motion analysis includes boundary crossing, zone penetration, sector access, and perimeter exit, with alarm activation support for specific targets: persons and vehicles.
Network Storage
NAS (NFS, SMB/CIFS)
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, UPnP, SMTP, UPnP-TM, P2P
Face Detection
N/A
System Compatibility
Onvif (Profile S, Profile G, T), SDK
Security
User authentication, IP address filtering, Video mask
Users
Maximum 40 users
Web Browsers
Internet Explorer 10 and 11 need a plug-in for live view support. Chrome 57.0+ and Firefox 52.0+ are required for local service.
Mobile Surveillance
iOS, Android
Communication Interface
1 RJ45 10 M/100 M Self-Adaptive Ethernet Port
Storage
Up to 256GB
NDAA Compliant
Completely
Operating Conditions
-30°C ~ 60°C (-22°F ~ 140°F) Humidity 95% or less (non-condensing)
Power Supply
DC12V ± 25%/ PoE (802.3 af)
Microphone
Supported
Power Consumption
Less than 6.5W
Protection Level
IP67
Speaker
N/A
Material
Metal
Audio I/O
N/A
Dimensions
Φ 68 × 172.3 mm (Φ 2.67’’ × 6.78’’)
Alarm I/O
N/A
Gross Weight
1.07lb / 485g
Active Deterrence Features
Red/Blue Light Warning
Humidity
95% or less (non-condensing)
PoE
PoE (802.3 af)
