Image Sensor
1/2.8” Progressive Scan CMOS Sensor
Minimum Illumination
Color: 0.006 Lux, 0 Lux with IR On
Illumination Distance
40m / 131.23ft (IR light)
Strobe Light
Supported
Smart IR
Supported
Pan / Tilt / Rotation Range
Pan: 0° ~ 360°, Tilt: 0° ~ 75°, Rotation: 0° ~ 360°
Focal Length
2.7 ~ 13.5 mm
Aperture
F1.6
Field of View
2.7 ~ 13.5 mm: Horizontal FOV: 108° ~ 34°, Vertical FOV: 58° ~ 19°, Diagonal FOV: 130° ~ 39°
Lens Mount
Φ 14
DORI
Detect: 93-274m; Observe: 36.3-108.1m; Recognize: 18.2-54.4m; Identify: 9.1-27.2m
Maximum Resolution
8MP (3840 × 2160)
Main Stream
50Hz: 25ips 8MP (3840 × 2160), 25ips 6MP (3200 × 1800), 25ips 5MP (3072 × 1728), 25ips 4MP (2560 × 1440), 25ips 1080P (1920 × 1080); 60Hz: 30ips 8MP (3840 × 2160), 30ips 6MP (3200 × 1800), 30ips 5MP (3072 × 1728), 30ips 4MP (2560 × 1440), 30ips 1080P (1920 × 1080)
Sub Stream
50Hz: 25fps 720P (1280 × 720), 25fps D1 (704 × 576), 25fps CIF (352 × 288) (Default D1); 60Hz: 30fps 720P (1280 × 720), 30fps D1 (704 × 480), 30fps CIF (352 × 240)
Image Setting
Brightness / Contrast / Saturation / Hue / Sharpness
Shutter Time
Auto/Manual, 1/3 ~ 1/100000s
Day/Night
IR Cut filter
Wide Dynamic Range
120 dB
Digital Noise Reduction
2D/3D DNR
BLC
Supported
HLC
Supported
ROI
Supported
Rotate
Supported
Video Compression
H.264 / H.264+ / H.265 / H.265+ / MJPEG
H.264 Codec Profile
Base / Main / High profile
H.265 Codec Profile
Main Profile
Video Bit Rate
11 Kbps ~ 16 Mbps
Triple Streams
Supported
Audio Compression
G.711A, G.711U
Audio Bit Rate
64 Kbps
Basic Events
Motion detection, Video Tampering
Smart Events
Line crossing detection, area intrusion, Monitoring entry and exit for specific regions (support alarm triggering by specified target types (human and vehicle) and Scene Alteration Detection
Face Detection
Supported
Network Storage
NAS (NFS, SMB/CIFS), ANR
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, UPnP, SMTP, UPnP-TM, P2P
System Compatibility
Onvif (Profile S, Profile G, T), SDK
Security
Password protection, complicated password, HTTPS encryption, IP address filter, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Users
Maximum 40 users
Web Browsers
Plug-in required live view: IE 10, IE 11; Local service: Chrome 57.0+, Firefox 52.0+
Mobile Surveillance
iOS, Android
Communication Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
Storage
Up to 256GB
Microphone
Supported
Audio I/O
1/1
Alarm I/O
1/1
Reset Button
Supported
Operating Conditions
-40°C ~ 60°C (-40°F ~ 140°F) Humidity 95% or less (non-condensing)
Power Supply
DC12V ± 25%
PoE
PoE (802.3 af)
Power Consumption
Less than 11W
Protection Level
IP67
Material
Metal
Dimensions
Φ 144.5 × 113.5 mm (Φ 5.68’’ × 4.47’’)
Gross Weight
2.43lb / 1100g
