NDAA Compliant
Yes
Lens Type
Fixed
Form Factor
Dome
Wide Dynamic Range
WDR 120dB or more
Inputs/Outputs
Without Inputs/Outputs
Audio In/Out
Without Audio In/Out
Megapixels
8 Megapixels
Image Sensor
1/2.8” Progressive Scan CMOS Sensor
Minimum Illumination
Color: 0.006 Lux (F1.6, AGC ON), 0 Lux with light
Illumination Distance
30m / 98.43ft (IR light)
Strobe Light
Supported
Smart IR
Supported
Pan / Tilt / Rotation Range
Pan: 0° ~ 355°; Tilt: 0° ~ 75°; Rotation: 0° ~ 355°
Focal Length
2.8mm
Aperture
F1.6
Field of View
2.8mm: Horizontal FOV: 106°, Vertical FOV: 58°, Diagonal FOV: 125°
Lens Mount
M12
DORI
Detection: 88m; Observe: 34.7m; Recognize: 17.4m; Identify: 8.7m
Maximum Resolution
8MP (3840 × 2160)
Frame Rate (Main Stream)
50Hz: 25fps 8MP (3840 × 2160), 25fps 6MP (3200 × 1800), 25fps 5MP (3072 × 1728), 25fps 4MP (2560 × 1440), 25fps 1080P (1920 × 1080); 60Hz: 30fps 8MP (3840 × 2160), 30fps 6MP (3200 × 1800), 30fps 5MP (3072 × 1728), 30fps 4MP (2560 × 1440), 30fps 1080P (1920 × 1080)
Frame Rate (Sub Stream)
50Hz: 25fps 720P (1280 × 720), 25fps D1 (704 × 576), 25fps CIF (352 × 288) (D1 par Défaut); 60Hz: 30fps 720P (1280 × 720), 30fps D1 (704 × 480), 30fps CIF (352 × 240)
Frame Rate (Third Stream)
50Hz: 25fps CIF (352 × 288); 60Hz: 30fps CIF (352 × 240)
Image Setting
Brightness / Contrast / Saturation / Hue / Sharpness
Shutter Time
Automatique/Manual, 1/3 ~ 1/100000s
Day/Night
IR Cut Filter
Wide Dynamic Range
120 dB
Digital Noise Reduction
DNR 2D/3D
BLC
Supported
HLC
Supported
ROI
Supported
Rotate
Supported
Video Compression
H.264 / H.264+ / H.265 / H.265+ / MJPEG
H.264 Codec Profile
Base / Main / High profile
H.265 Codec Profile
Main Profile
Video Bit Rate
11 Kbps ~ 16 Mbps
Triple Streams
Supported
Audio Compression
G.711A, G.711U
Audio Bit Rate
64 Kbps
Basic Events
Motion Detection (supports alarm activation based on designated target types, including humans and vehicles), Video Tampering
Smart Events
Smart Motion Detection, Line Crossing, Intrusion Detection, Monitoring entry and exit for specific regions (with alarm triggers for the detection of humans and vehicles), Scene Alteration Detection
Face Detection
Supported
Network Storage
NAS (NFS, SMB/CIFS), ANR
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, UPnP, SMTP, UPnP-TM, P2P
System Compatibility
Onvif (Profile S, Profile G, T), SDK
Security
Password protection, complex passwords, HTTPS encryption, IP address filtering, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Users
Maximum 40 users
Web Browsers
Plug-in required live view: IE 10, IE 11; Local service: Chrome 57.0+, Firefox 52.0+
Mobile Surveillance
iOS, Android
Communication Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
Storage
Up to 256GB
Microphone
Supported
Speaker
N/A
Audio I/O
N/A
Alarm I/O
N/A
Reset Button
Supported
Operating Conditions
-40°C ~ 60°C (-40°F ~ 140°F)
Humidity
95% or less (non-condensing)
Power Supply
DC12V ± 25%
PoE
PoE (802.3 af)
Power Consumption
Less than 9W
Protection Level
IP67
IK Rating
IK10
Material
Metal
Dimensions
Φ 114 × 91.8 mm (Φ 4.49’’ × 3.61’’)
Gross Weight
1.76lb / 800g
