Wide Dynamic Range
WDR 120dB or more
Audio In/Out
With Audio Inputs and/or Outputs
NDAA Compliant
Yes
Inputs/Outputs
With Inputs/Outputs
Lens Type
Auto Focus
Form Factor
PTZ
Megapixels
5 Megapixels
Image Sensor
1/2.8” Progressive Scan CMOS Sensor
Minimum Illumination
Color: 0.005 Lux at F1.6, B/W: 0.0005 Lux at F1.6, 0 Lux with IR light on
Illumination Distance
200m / 656.2ft (IR light), 50m / 164.04ft (Warm light)
Illumination
4 IR LED, 2 Laser, 4 White light LED
Active Deterrence LED
1 Red light and 1 Blue light
Wavelength
850nm
IR On/Off Control
Automatique/Manual
Shutter Time
Auto/Manual, 1/1 ~ 1/100000s
Smart IR
Supported
S/N Ratio
>56dB
Focal Length
32x optical zoom / 16x digital zoom, 4.8 ~ 154 mm
Aperture
F1.6 ~ F4.3
Field of View
4.8 ~ 154 mm: Horizontal FOV: 54.4° ~ 2.3°, Vertical FOV: 41.1° ~ 1.7°, Diagonal FOV: 67.2° ~ 2.8°
Zoom Speed
5.66s
Focus Control
Auto, Semi-Auto, Manual
DORI Distance
Detection: 109m; Observe: 43.6m; Recognize: 21.8m; Identify: 10.9m (4.8 mm) Detection: 2500m; Observe: 1000m; Recognize: 500m; Identify: 250m (154 mm)
Maximum Resolution
5MP (2592 × 1944)
Frame Rate (Main Stream)
50Hz: 25ips: 2592 × 1944, 2304 × 1728, 1920 × 1080, 1280 × 960, 1280 × 720; 60Hz: 30fps: 2592 × 1944, 2304 × 1728, 1920 × 1080, 1280 × 960, 1280 × 720
Frame Rate (Sub Stream)
50Hz: 25ips: (704 × 576, 640 × 480, 352 × 288); 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Frame Rate (Third Stream)
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288); 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
U-code
H.264+ / H.265+
Image Setting
Brightness / Contrast / Saturation / Hue / Sharpness
White Balance
Supported
Day/Night
IR Cut Filter with Auto Switch
Wide Dynamic Range
130 dB
Digital Noise Reduction
2D/3D DNR
BLC, HLC, ROI, Starlight
Supported
RotateX
Supported
Video Compression
Main Stream: H.265+ / H.265 / H.264+ / H.264; Sub Stream: H.265 / H.264 / MJPEG; Third Stream: H.265 / H.264
H.265 Code C Profile
Main Profile
H.254 Code C Profile
Base Profile / Main Profile / High Profile
Video Bit Rate
32Kbps ~ 16Mbps
Triple Streams
Support
Audio Compression
Auto/Manual
Two-way Audio
Supported
Suppression
Supported
Sampling Rate
8KHz
Basic Event
Motion Detection, Video Tampering
Smart Event
Smart motion detection, line crossing, area intrusion, region entrance, region exiting (support alarm triggering by specified target types (human and vehicle))
Auto Tracking
Supported
Face Detection
Supported
Active Deterrence
Red & Blue warning light and supported sound warning
Network Storage
NAS (NFS / CIFS)
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, UPnP, SMTP, UPnPTM, P2P
System Compatibility
ONVIF (Profile S, Profile G, Profile T0, CGI
Security
User Authentication, IP address filtering
User
40
Software
ARKIV, Legend NX
Web Browser
Live view plug-in required: IE 10, IE 11 Local Service: Chrome 57.0 and + and Firefox 52.0 and +
Mobile Surveillance
IOS, Android
Communication Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
Storage
Up to 512 GB
Built-in Mic
Supported
Built-in Speaker
Supported
Audio I/O
1/1
Alarm I/O
2/1
Serial Port
N/A
Video Output
N/A
Reset Button
Supported
Pan Range
360° endless
Pan Speed
Pan Speed
Tilt Range
–15° to +90° (auto flip 180°)
Tilt Speed
Configurable from 0.1° to 80°/s, preset speed 200°/s
Proportional Zoom
Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset
255
Power-off Memory
Supported
Patrol
32 Automatic patrols
Preset Patrol
32 patrols, up to 32 presets for each patrol
Route Patrol
Supported
Recorded Patrol
8 patrols, up to 128 actions for each patrol
Patrol Stay Time
15s ~ 255s
Preset Image Freeze
N/A
Home Position
Supported
3D Positioning
Supported
Operating Conditions
( -40 °C ~ 70 °C ) ( -40 °F ~ 158 °F ); Humidity 95% or less (non-condensing)
Power Supply
DC36V
Power Consumption
Max 30W
Power Interface
Pressed wire connectors with a spacing of 8mm
Protection Level
IP67
Surge Protection
6000V lightning protection, surge protection and anti-surge protection
Dimensions
φ190 × 339.8mm (7.48’’ × 13.38’’)
Weight
7650g / 16.86 lb
