Image Sensor
1/2.8’’, 5.0 megapixel, progressive scan, CMOS
Minimum Illumination
Color: 0.01 Lux (F2.0, AGC ON); 0 Lux with IR
Focal Length
1.4mm
DORI Distance
Detect: 31.5m; Observe: 12.6m; Recognize: 6.3m; Identify: 3.2m
Compression
H.265+ / H.265 / H.264 / MJPEG
Frame Rate
Main Stream: (2592×1944): Max.30fps; Sub Stream: (1920×1080): Max.30fps; Third Stream: D1(720 x 576): Max.30 fps
Edge Storage
Micro SD slot, up to 256 GB
Power Supply
DC 12V ± 25%, PoE (IEEE 802.3af )
Weight
0.86 lb (0.39kg)
Dimensions
125 × 43.7 mm (4.9” × 1.7”)
Intelligent Search
Heat Map
Minimum Illumination
Color: 0.01 Lux (F2.0, AGC ON); 0 Lux with IR
Focal Length
1.4mm
DORI Distance
Detect: 31.5m; Observe: 12.6m; Recognize: 6.3m; Identify: 3.2m
Compression
H.265+ / H.265 / H.264 / MJPEG
Frame Rate
Main Stream: (2592×1944): Max.30fps; Sub Stream: (1920×1080): Max.30fps; Third Stream: D1(720 x 576): Max.30 fps
Protocol
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSH
Security
Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF, Password protection, Strong password, HTTPS encryption
Compatibility
ONVIF (Profile S, Profile G, Profile T), API
Management Software
LEGEND VMS / ARKIV
Ethernet
1 RJ45 10M/100M Base-TX Auto-adaptive Ethernet
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1 ~ 1/100,000s
S/N Ratio
More than 55dB
IR Distance
Distance up to 10M (33ft)
Wide Dynamic Range
120dB
Day/Night
IR-cut filter with auto switch (ICR)
Wavelength
850nm
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked
Noise Reduction
2D/3D DNR
Flip
Normal/Flip Vertical/ Flip Horizontal/180°
Privacy Masking
Up to 4 areas
OSD
Up to 8 OSDs
Smart IR
Supported
Motion Detection
Up to 4 areas
BLC
Supported
Region of Interest
Up to 8 areas
General Functions
Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication
Lens Type
Fixed Lens
Angle of View
360°
Bit Rate
128 Kbps~16 Mbps
Mount Type
Support table, wall, and ceiling
Decoding Mode
Support software decoding
Display Mode
11 display modes in total
Intelligent Search
Heat Map
Detection
Motion detection, Tampering alarm, Audio detection
Audio Compression
G.711
Suppression
Supported
Sampling Rate
8KHZ
Built-in Microphone
2 Supported
Audio I/O
Input: impedance 35 kΩ; amplitude 2 V [p-p] Output: impedance 600 Ω; amplitude 2 V [p-p]
Alarm I/O
1/1
Edge Storage
Micro SD slot, up to 256 GB
Network Storage
ANR, NAS(NFS)
Certifications
FCC (FCC CFR 47 part15 B, ANSI C63.4-2014); CE LVD (EN 62368-1:2014+A11:2017); UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Power Supply
DC 12V ± 25%, PoE (IEEE 802.3af)
Power Consumption
Less than 8.5W
Working Environment
-30° C to +60° C (-40°F to 140°F)/ Less than 95% RH
Protection (Ingress, Vandal, Surge)
IP66; IK10; 4KV
Material
Metal + Plastic
Weight
0.79 lb (0.36kg)
Dimensions
Φ125 × 43.7 mm (Φ4.9” × 1.7”)
