Image Sensor
1/2.7”, 2 Megapixel, progressive scan, CMOS
Minimum Illumination
Color: 0.01 Lux (F2.0, AGC On); 0 Lux with IR on
Features
HLC; BLC; WDR 120dB
Image Setting
Image rotation, brightness, saturation, contrast, sharpness, gain adjustable by web browser
Flip
Normal / Vertical / Horizontal / 180° / 90°Clockwise / 90°Anti-clockwise
Privacy Masking
Up to 4 areas
Advanced Detection Tools
Human Body Detection
OSD
Up to 4 OSDs
Region of Interest
Up to 8 areas
Compliance
NDAA
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1~1/100,000 s
S/N Ratio
More than 52dB
IR Distance
Distance up to 30m (98ft)
Day/Night
IR-cut filter with auto switch (ICR)
Smart IR
Support
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked
Noise Reduction
2D/3D DNR
Motion Detection
Up to 4 areas
Defog
Digital Defog
Lens Type
Fixed Lens
Focal Length
2.8mm
Viewing Angle
H: 112.9°; V: 59.1°; O: 121.2°
Pan/Tilt/Rotate
Pan: 3° ~ 360°; Tilt: 0 ~ 90°; Rotate: 0 ~ 360°
DORI Distance
Detect: 42.0m; Observe: 16.8m; Recognize: 8.4m; Identify: 4.2m
Compression
H.265+, H.265, H.264, MJPEG
H.264 code profile
Baseline profile, Main profile
Frame Rate
Main Stream: 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps // Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
Video Bit Rate
128 Kbps ~ 6144 kbps
Edge Storage
Micro SD, up to 128GB
Network Storage
ANR, NAS(NFS)
Ethernet
1 RJ45 10M/100M Base-TX Ethernet
Protocol
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS, SSL/TLS, SNMP
Compatibility
ONVIF (Profile S, Profile G, Profile T), API, SDK
Security
Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
User/Host
Up to 32 users. 2 user levels: administrator and common user
Management Software
LEGEND VMS / ARKIV
Web Browser
Live view with plug-in required: Firefox 52 and below, Chrome 41 and below, IE9+ // Live view without plug-in: Firefox 58.0+, Chrome 57.0+, Edge 16+
Audio Compression
G.711
Suppression
Supported
Sampling Rate
8KHZ
Built-in Microphone
Supported
EMC
FCC: FCC Part 15
Safety
CE: EN 60950-1, UL: UL60950-1, IEC 60950-1
Power Supply
DC 12V±25%, PoE (IEEE 802.3af)
Power Consumption
Less than 7.0W
Working Environment
-30°C to 60°C (-22°F to 140°F) / Less than 95% RH
Material
Metal
Ingress & Surge Protection
IP67; 4KV
Weight
0.86 lb (0.39kg)
Dimensions
165 × 63 × 62mm (6.5” × 2.5” × 2.5”)
