Image Sensor
1/2.7” Progressive Scan CMOS Sensor
Minimum Illumination
Color: 0.006 Lux (F1.6, AGC ON), 0 Lux with light
Illumination Distance
30m / 98.43ft (IR light) 30m/98.43ft (Warm light)
Strobe Light
N/A
Smart IR
Supported
Pan/Tilt/Rotation Range
Pan: 0° ~ 360°, Tilt: 0° ~ 75°, Rotation: 0° ~ 360°
Focal Length
2.8mm
Aperture
F1.6
Field of View
2.8mm: Horizontal: 114°, Vertical: 61°, Diagonal: 135°
Lens Mount
M12
Maximum Resolution
5MP (2960 × 1664)
Main Stream
50Hz: 20ips 5MP (2960 × 1664), 25ips 4MP (2688 × 1520), 25ips 4M (2560 × 1440), 25ips 1080P (1920 × 1080); 60Hz: 20ips 5MP (2960 × 1664), 30ips 4MP (2688 × 1520), 30ips 4M (2560 × 1440), 30ips 1080P (1920 × 1080)
Sub Stream
50Hz: 25ips 720P (1280 × 720) 25ips D1 (704 × 576), 25ips CIF (352 × 288); 60Hz: 30ips 720P (1280 × 720) 30ips D1 (704 × 480), 30ips CIF (352 × 240)
Third Stream
50Hz: 25ips CIF (352 × 288); 60Hz: 30ips CIF (352 × 240)
Image Setting
Brightness / Contrast / Saturation / Hue / Sharpness
Shutter Time
Auto/Manual, 1/3 ~ 1/100000s
Day/Night
IR Cut filter
Wide Dynamic Range
120 dB
Digital Noise Reduction
2D/3D DNR
BLC
Supported
HLC
Supported
ROI
Supported
Rotate
Supported
Video Compression
H.264 / H.264+ / H.265 / H.265+ / MJPEG (sub stream)
H.264 Codec Profile
Base / Main / High profile
H.265 Codec Profile
Main Profile
Video Bit Rate
11 Kbps ~ 10 Mbps
Triple Streams
Supported
Audio Compression
G.711A, G.711U
Audio Bit Rate
64 Kbps
Basic Events
Motion detection, Video Tampering
Smart Events
Line crossing detection, area intrusion, Monitoring entry and exit for specific regions (support alarm triggering by specified target types (human and vehicle)
Face Detection
N/A
Network Storage
NAS (NFS, SMB/CIFS), ANR
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, UPnP, SMTP, UPnP-TM, P2P
System Compatibility
Onvif (Profile S, Profile G, T), SDK
Security
User authentication, IP address filtering, Video mask
Users
Maximum 40 users
Web Browsers
Plug-in required live view: IE 10, IE 11; Local service: Chrome 57.0+, Firefox 52.0+
Mobile Surveillance
iOS, Android
Communication Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
Storage
Up to 256GB
Microphone
Supported
Speaker
N/A
Audio I/O
N/A
Alarm I/O
N/A
Reset Button
Supported
Active Deterrence Features
Red/Blue Light Warning
Operating Conditions
-40°C ~ 60°C (-40°F ~ 140°F) Humidity 95% or less (non-condensing)
Power Supply
DC12V ± 25%; PoE (802.3 af)
Power Consumption
Less than 6W
Protection Level
IP67
Material
Metal
Dimensions
Φ 103.5 × 82.4 mm (Φ 4.07’’ × 3.24’’)
Gross Weight
0.99lb / 450g
