Camera Features
-
Image Sensor
1/3”, 4.0 megapixel, progressive scan, CMOS
Minimum Illumination
Color: 0.002Lux (F1.6, AGC ON) / 0 Lux with IR on
Scanning System
Progressive
Wide Dynamic Range
120dB
Electronic Shutter Speed
Auto/Manual, 1 ~ 1/100 000s
Lens Type
Fixed
Minimum Illumination
Color: 0.01 lux (F2.0 AGC ON) 0 lux with IR
Focal Length
2.8mm
S/N Ratio
More than 56dB
DORI Distance
Detect: 63m / Observer: 25.2m / Recognize: 12.6m / Identify: 6.3m
IR Distance
Distance up to 30M (98ft)
Compression
H.265+ / H.265 / H.264 / MJPEG
IR On/Off Control
Auto/Manual
Frame Rate
Main Stream: 4MP (2688 x 1520) Max 30fps; 4MP (2560 x 1440) Max 30fps
Day/Night
IR-cut filter with auto switch (ICR)
Bit Rate
128 Kbps ~ 16 Mbps
BLC
Supported
Microphone
Built-in Mic
White Balance
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked
Edge Storage
Micro SD slot, up to 256 GB
Noise Reduction
2D/3D DNR
Intrusion
Line Crossing detection, Intrusion detection, Exiting an Area detection, Enter Area
Flip
Normal/Vertical/Horizontal/180°
Detection
Motion detection, tampering alarm, audio detection
Defog
Digital Defog
Power Supply
DC 12V ± 25%, PoE (IEEE 802.3af )
Privacy Masking
Up to 4 areas
Power Consumption
Less than 4W
OSD
Up to 8 OSDs
Ingress Protection
IP67
Smart IR
Supported
Weight
0.42kg (0.93lb)
Lens Type
Fixed
Dimensions
110.5 x 94.1mm (4.4” x 3.7”)
Focal Length
2.8mm
NVR Features
-
Viewing Angle
H: 97°; V: 52.2°; O: 107.5°
IP Video Input
8-Channel
Pan/Tilt/Rotate
Pan: 0° ~ 360°; Tilt: 0 ~ 75°; Rotate: 0° ~ 360°
Incoming Bandwidth
80Mbps
DORI Distance
Detect: 63m / Observer: 25.2m / Recognize: 12.6m / Identify: 6.3m
Outgoing Bandwidth
64Mbps
Compression
H.265+ / H.265 / H.264 / MJPEG
Recording Resolution
4K / 5MP / 4MP / 3MP / 1080p / 960p / 720p / D1 / 2CIF / CIF
H.264 code profile
Baseline profile, Main profile, High profile
Liveview Display
1 / 4 / 6 / 8 / 9
Frame Rate
Main Stream: 4MP (2560x1440), Max 25fps; 3MP (2304x1296), Max 30fps; 1080P (1920x1080), Max 30fps; 720P (1280x720), Max 30fps // Sub Stream: 720P (1280 x 720) Max 30fps; D1 (720 x 576) Max 30fps; 640x360 Max 30fps; 2CIF (704 x 288) Max 30fps; CIF (352 x 288) Max 30fps // Third Stream: D1 (720 x 576) Max 30fps; 640 x 360 Max 30fps; 2CIF (704 x 288) Max 30fps; CIF (352 x 288) Max 30fps
Corridor Mode Screen
3 / 4 / 5 / 7 / 9
Bit Rate
128 Kbps ~ 16 Mbps
Decoding Format
H.265+ / H.265 / H.264
Ethernet
1 RJ45 10M/100M Base-TX Ethernet
SATA HDD
Up to 1 SATA HDD
Protocol
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS, SSL/TLS, SNMP
Storage
Up to 8TB for each disk
Compatibility
ONVIF (Profile S, Profile G, Profile T), API,SDK
Camera Smart Detection
Auto Tracking, Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed
Management Software
LEGEND VMS, Arkiv
People Counting
People Flow Counting, Crowd Density Monitoring
Edge Storage
Micro SD slot, up to 128 GB
Power Supply
52V DC / Power Consumption: Less than 8W (without HDD)
Network Storage
ANR, NAS(NFS)
Dimensions (WxDxH)
260mm × 240mm × 47mm (10.2”×9.4”×1.9 “)
Perimeter Protection functions
Line Crossing & Intrusion (Human only)
Weight (without HDD)
2.20 lbs (Up to 1kg)
Detection
Motion Detection, Tampering Alarm
General Function
Watermark, IP address filtering, Tampering alarm, Access policy, ARP protection, RTSP authentication, User authentication
Certifications
EMC: CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020); FCC: (FCC CFR 47 part15 B, ANSI C63.4-2014) Safety CE LVD (EN 62368-1:2014+A11:2017) CB (IEC 62368-1:2014) UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01); Environment: CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006); Protection: IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013)
Power Supply
DC 12V ± 25%, PoE (IEEE 802.3af )
Power Consumption
Less than 4W
Working Environment
-30° C to +60° (-22°F ~ 140°F) / Less than 95% RH (non-condensing)
Ingress Protection
IP67
Weight
0.66lb (0.30kg)
Dimensions
Φ118 x 97mm (Φ4.6” x 3.8”)
NVR Features
-
IP Video Input
8-Channel
Incoming Bandwidth
80Mbps
Outgoing Bandwidth
64Mbps
Remote Users
128
Protocols
TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SMTP, RTSP
HDMI/VGA Output
HDMI: 3840 x 2160 at 30Hz; 1920 x 1080p at 60Hz; 1920 x 1080p at 50Hz; 1600 x 1200 at 60Hz; 1280 x 1024 at 60Hz; 1280 x 720 at 60Hz; 1024 x 768 at 60Hz // VGA: 1920 x 1080p at 60Hz; 1920 x 1080p at 50Hz; 1600 x 1200 at 60Hz; 1280 x 1024 at 60Hz; 1280 x 720 at 60Hz; 1024 x 768 at 60Hz
Recording Resolution
4K / 5MP / 4MP / 3MP / 1080p / 960p / 720p / D1 / 2CIF / CIF
Audio Output
1-Channel, RCA
Audio Compression
G.711A, G.711U
People Counting
People Flow Counting, Crowd Density Monitoring
Synchronous Playback
8-Channel
Liveview Display
1 / 4 / 6 / 8 / 9
Corridor Mode Screen
3 / 4 / 5 / 7 / 9
FTP/Schedule/ Event Snapshot
1-ch snapshot, up to D1 resolution
Decoding Format
H.265+ / H.265 / H.264
Liveview/Playback
8MP / 5MP / 4MP / 3MP / 1080p / 960p / 720p / D1 / 2CIF / CIF
Capability
1 x 4K at 30fps; 4 x 5MP at 25fps; 4 x 4MP at 25fps; 8 x 720P at 30fps
SATA HDD
Up to 1 SATA HDD
Storage
Up to 8TB for each disk
Camera Smart Detection
Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Audio Detection, Smart Motion Detection
Smart Search
Face Search, Behavior Search
Smart Intrusion Prevention
4-Channel
Trigger Events
Motion, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection, IP Conflict, Network Disconnected, Disk Offline , Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal
Network Interface
1 RJ45 10M/100M self-adaptive Ethernet Interface
USB Interface
Rear panel: 2 x USB2.0
Interface
8 RJ45 10M/100M self-adaptive Ethernet Interface
Maximum Capacity
Max: 30W for single port; Max: 75W in total
Supported Standard
IEEE 802.3at, IEEE 802.3af
Certification
Certification: CE CE, FCC, UL, RoHS, WEEE; CE: EN 55032: 2015, EN 61000-3-3: 2013, EN IEC 61000-3-2: 2019, EN 55035: 2017; FCC: Part15 Subpart B, ANSI C63.4
Power Supply
52V DC / Power Consumption: Less than 8W (without HDD)
Working Envrionment
-10°C to +55°C; Less than 90% RH (non-condensing)
Dimensions (WxDxH)
260mm × 240mm × 47mm (10.2”×9.4”×1.9 “)
Weight (without HDD)
2.20 lbs (Up to 1kg)
