Enregistreurs Vidéo Plug-and-Play
Enregistreurs IP NDAA Legend
Canaux
16 Canaux
Raid
Sans
IP Video Input
16-Channel
IP Video Input
16-Channel
Two-way Audio Input
1-Channel, RCA
Incoming Bandwidth
160Mbps
Outgoing Bandwidth
64Mbps
Maximum Operators
32
Protocols
TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP
HDMI/VGA Output
HDMI: 3840 x 2160 at 30fps; 1920 x 1080 at 60fps; 1920 x 1080 at 50fps; 1600 x 1200 at 60fps; 1280 x 1024 at 60fps; 1280 x 720 at 60fps; 1024 x 768 at 60fps // VGA: 1920 x 1080 at 60fps, 1920 x 1080 at 50fps, 1280 x 1024 at 60fps, 1280 x 720 at 60fps, 1024 x 768 at 60fps
Recording Resolution
8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 960p / 720p / D1 / 2CIF / CIF
Audio Output
1-Channel, RCA
Audio Compression
G.711A, G.711U
Synchronous Playback
16-Channel
Liveview Display
1 / 4 / 6 / 8 / 9 / 16
Corridor Mode Screen
3 / 4 / 5 / 7 / 9 / 10 / 12 / 16
Decoding Format
H.265+ / H.265 / H.264
Liveview/Playback
8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 960p / 720p / D1 / 2CIF / CIF
Capability
2 x 4K at 30fps, 4 x 4MP at 30fps, 5 x 3MP at 30fps, 8 x 1080P at 30fps, 16 x 720P at 30fps
SATA HDD
Up to 2 SATA HDDs
Storage
Up to 10TB for each disk
Camera Smart Detection
Auto Tracking, Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed
Smart Search
Behavior Search
People Counting
People Flow Counting, Crowd Density Monitoring
Smart Intrusion Prevention
8-Channel
Trigger Events
Motion, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection, IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/ Snapshot Abnormal
Network Interface
1 RJ45 10M/100M self-adaptive Ethernet Interface
USB Interface
Front panel: 1 x USB2.0, Rear panel: 1 x USB 3.0
Alarm In/Out
4-Channel / 1-Channel
ONVIF conformance
Profile S/G/T and RTSP protocols
Interface
16 RJ-45 10M/100M self-adaptive Ethernet Interface
Maximum Capacity
Max: 30W for single port, Max: 240W in total
Supported Standard
IEEE 802.3af/at
Certifications
CE, FCC, UL, RoHS, WEEE
CE
EN 55032: 2015, EN 61000-3-3: 2013, EN IEC 61000-3-2: 2019, EN 55035: 2017
FCC
Part15 Subpart B, ANSI C63.4
Power Supply
100 ~ 240 V AC / Power Consumption: Less than 10W (without HDD)
Working Envrionment
-10°C to +55°C; Less than 90% RH (non-condensing)
Dimensions (WxDxH)
380mm × 315mm × 53mm (14.9” × 12.4” ×2.1”)
Weight (without HDD)
5.73 lbs (Up to 2.6kg)
