Enregistreurs Vidéo Plug-and-Play
Enregistreurs IP NDAA Legend
Canaux
4 Canaux
Raid
N/A
IP Video Input
4-Channel
IP Video Input
4-Channel
Two-way Audio Input
1-Channel, RCA
Incoming Bandwidth
80Mbps
Outgoing Bandwidth
64Mbps
Maximum Operators
32
Protocols
TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP
HDMI/VGA Output
HDMI: 3840 x 2160 at 30Hz; 1920 x 1080p at 60Hz; 1920 x 1080p at 50Hz; 1600 x 1200 at 60Hz; 1280 x 1024 at 60Hz; 1280 x 720 at 60Hz; 1024 x 768 at 60Hz // VGA: 1920 x 1080p at 60Hz; 1920 x 1080p at 50Hz; 1600 x 1200 at 60Hz; 1280 x 1024 at 60Hz; 1280 x 720 at 60Hz; 1024 x 768 at 60Hz
Recording Resolution
4k / 5MP / 4MP / 3MP / 1080P / 960P / 720P / D1 / 2CIF / CIF
Audio Output
1-Channel, RCA
Audio Compression
G.711A, G.711U
Synchronous Playback
4-Channel
Liveview Display
1 / 4
Corridor Mode Screen
3 / 4
Decoding Format
H.265+ / H.265 / H.264
Liveview/Playback
8MP / 5MP / 4MP / 3MP / 1080p / 960p / 720p / D1 / 2CIF / CIF
Capability
2 x 4K at 30fps; 3 x 5MP at 30fps; 4 x 4MP at 30fps
SATA HDD
Up to 1 SATA HDD
Storage
Up to 8TB for each disk
Camera Smart Detection
Auto Tracking, Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed
Smart Search
Behavior Search
People Counting
People Flow Counting, Crowd Density Monitoring
Smart Intrusion Prevention
4-Channel
Trigger Events
Motion, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection, IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/ Snapshot Abnormal
Network Interface
1 RJ45 10M/100M self-adaptive Ethernet Interface
USB Interface
Rear panel: 1 x USB2.0, 1 x USB 3.0
ONVIF conformance
Profile S/G/T and RTSP protocols
Interface
4 RJ45 10M/100M self-adaptive Ethernet Interface
Maximum Capacity
Max: 30W for single port, Max: 54W in total
Supported Standard
IEEE 802.3at, IEEE 802.3af
Certifications
CE, FCC, UL, RoHS, WEEE
CE
EN 55032: 2015, EN 61000-3-3: 2013, EN IEC 61000-3-2: 2019, EN 55035: 2017
FCC
Part15 Subpart B, ANSI C63.4
Power Supply
48V DC / Power Consumption: Less than 9W (without HDD)
Working Envrionment
-10°C to +55°C; Less than 90% RH (non-condensing)
Dimensions (WxDxH)
260mm × 240mm × 47mm (10.2” × 9.4” × 1.9“)
Weight (without HDD)
2.20 lbs (Up to 1kg)
